SPECIFICATIONS



Type: GasolineChainsa



---

Product Description

• High Performance: WEMARS 62cc 20 inch powerful gas chainsaw with guide bar and chain for cutting wood that need a longer bars. 2 stroke motors with integrated chain brake for safety and stable while operating. Low kickback safety function and excellent electronic ignition system can reduce the risk during operation
• Tension Adjustment: Automatic chain lubricator adjustable chain oil feed and quick and easy chain tension adjustment. The rugged 20 inch steel chain saw knob-type automatic tightening function is a side-adjustable chain that is easy to operate and maintain while delivering the highest cutting performance
• Reasonable Design: The combination of ergonomic front and back anti-vibration handles, cushioned wrap handles and balanced design make the gasoline chain saw easy to use and comfortable to operate. Chainsaws suitable conquer tree felling, wood cutting for lumberjacks in the forest or other use
• System Functions: WEMARS 20" bar gasoline powered chain saw is equipped with a filter system to ensure a long air filter life. The automatic lubrication system reduces the risk of wear and damage of the starter mechanism and prolongs using life. Effortless pull starting system, start faster, higher reliability
• Air Filter: The quick-release air filter facilitates easy cleaning and replacement of the air filter, and the high performance , huge power direct air injection carburettor reduces emission levels and fuel consumption. Maximizes run time and chain saw motor life





Automatic Chain Lubricator Automatic chain lubricator adjustable chain oil feed and quick and easy chain tension adjustment	Exhaust Muffler The quick-release air filter facilitates easy cleaning and replacement of the air filter, and the high performance	High Performance Low kickback safety function and excellent electronic ignition system can reduce the risk during operation









How to use the chainsaw:

1. Pull the Throttle Control Drawbars to Close the Throttle

2. Push the Fflameout Switch to the Starting Position (I)

3. Pull the starting handlebar outward several times until there's ignition sounds. Reset the throttle control drawbars and open the choke and start the handle repeatedly until the engine starts

4. Press the Trigger and Release the Engine to Idle

5. Place the Flameout Switch at (o) to Turn Off the Engine

Note: After the first ignition sound, closing the choke and repeatedly pulling on the start handle will suck in too much fuel and prevent the engine from starting

To start clod engine step follow:

1. Switch button up 2. Choke out fully

3. Hold the trigger and trigger lockout press the lock button

4. Pull the starter rope (max 6 times ) stop pull when engine warm up ( engine fire / motor sound)

5. Push the choke back fully (not half )

6. Pull the starter rope again ( max 20times )

Note : our warm up sometime not so strong as you know , but even you pass , please push choke back fully after 6 times pulling





How to Install Chain:

1. Remove the bar nuts and the sprocket cover. Remove the transportation guard

2. insall pump spike

3. Put the guide bar above the bar bolts. Steer the guide bar to its most rear position

4. Lift the saw chain above the drive sprocket and engage it in the groove on the guide bar. Start on the top edge of the guide bar

5. Assemble the sprocket cover and steer the chain adjuster pin to the hole in the guide bar. Make sure that the drive links of the saw chain fit correctly on the drive sprocket. Also make sure that the saw chain is correctly engaged in the groove in the guide bar

6. Tighten the guide bar nuts with your fingers

7. Tighten the saw chain by turning the chain tensioning screw clockwise with the combination wrench

8. Tighten the saw chain until it does not sag from below the guide bar, but you can turn it easily by hand. Adjust the tightness of the chain saw, which is about 0.4-0.6 inch

9. Hold up the end of the guide bar and tighten the bar nuts with the combination wrench

Note:

1. Empty you oil tank when you don't use. If not the oil will keep coming out

2. The product has an automatic lubrication system. The saw chain oil tank and the fuel tank are designed so that the fuel runs out before the saw chain oil. This safety feature requires that the correct chain oil is used and that the instructions are obeyed
